ARi Industries Inc.

Base Metal AerOpak®

BASE METAL THERMOCOUPLE

Our standard mineral insulated (MI) thermocouple cable starts with fully annealed and cleaned tubing, high-purity (99.4% minimum) MgO insulation material and thermocouple wire that meet per ASTM E-230 Special Limits of Error. In the ARi production process, precise dimensionality and uniform insulation maintained throughout the multiple reduction drawing and annealing process, assuring the end product integrity. All commercially available thermocouple, conductor and heater wire materials are offered as standards from ARi.

The Quality Standard:

Useable under sever conditions that can destroy other types of thermocouple cable.Withstands temperatures up to metal melting points.Withstands corrosive conditions that are limited only by the choice of the outer sheath material.Can be formed around a solid mandrel that is twice the sheath diameter without loss of integrity. Can be welded, brazed or soldered to the other metals when proper techniques are used.Standardized and shipped from ARi stock.
